Была свободная минутка - вскрыл фм Хелдивера.
https://www.sas1946.com/main/index.p...c,68897.0.html
Осталось много вопросов...
---------------------------------
Без тестов, завтра будут.
Код:
[Aircraft]
Type 1
Crew 2
Wingspan 10.36
Length 8.574
Seaplane 0
Canard 0
Jet 0
JetHiV 0
[Mass]
Empty 1936.0
TakeOff 2700.0
Oil 30.0
Fuel 360.0
[Controls]
CAileron 1
CAileronTrim 1
CElevator 1
CElevatorTrim 1
CRudder 1
CRudderTrim 1
CFlap 1
CFlapPos 3
CDiveBrake 1
CInterceptor 0
CEngine 1
CVectoredThrust 0
CUndercarriage 1
CLockTailwheel 0
CStabilizer 0
CArrestorHook 1
CWingFold 0
CCockpitDoor 1
CockpitDoorPeriod 3.0
CAileronThreshold 320.0
CRudderThreshold 320.0
CElevatorThreshold 360.0
DefaultAileronTrim 0.009
DefaultElevatorTrim 0.00
DefaultRudderTrim 0.087
[Squares]
Wing 29.50
Aileron 1.87
Flap 2.28
Stabilizer 1.45
Elevator 1.4
Keel 0.95
Rudder 1.15
Wing_In 5.1
Wing_Mid 5.1
Wing_Out 4.55
FuselageCxS 0.00
AirbrakeCxS 0.104
[Arm]
Aileron 2.8
Flap 2.4
Stabilizer 4.4
Keel 4.4
Elevator 4.62
Rudder 4.62
Wing_In 1.25
Wing_Mid 2.75
Wing_Out 3.50
GCenter 0.045
GCenterZ 0.00
GC_AOA_Shift 0.44
GC_Flaps_Shift 0.15
GC_Gear_Shift -0.35
[Toughness]
AroneL 50
AroneR 50
CF 500
Engine1 350
Engine2 350
Engine3 350
Engine4 350
GearL2 200
GearR2 200
Keel1 80
Keel2 100
Nose 80
Oil 80
Rudder1 80
Rudder2 100
StabL 80
StabR 100
Tail1 150
Tail2 180
Turret1B 100
Turret2B 100
Turret3B 100
Turret4B 100
Turret5B 100
Turret6B 100
VatorL 80
VatorR 100
WingLIn 150
WingLMid 100
WingLOut 100
WingRIn 150
WingRMid 100
WingROut 100
Flap01 50
Flap02 50
Flap03 50
Flap04 50
[Engine]
Engine0Family PrattWhitney_R-1830_Series(MOD):SBC_3_FM
Engine0SubModel R-1535-SB4-G/Twin-Wasp/SBC-3
[Gear]
H 1.54
Pitch 16.8
SinkFactor 1000.0
SpringsStiffness 0.5
TailStiffness 0.2
[Params]
CriticalAOA 19.50
CriticalCy 01.35
CxCurvature 00.72
CxStraightness 00.123
CriticalAOAFlap 16.50
CriticalCyFlap 01.80
SpinTailAlpha 17.00
SpinCxLoss 0.08
SpinCyLoss 0.03
Vyfac 1.0
Tfac 1.03
Vmin 120.0
Vmax 320.0
VmaxAllowed 650.0
VmaxH 348.0
HofVmax 3500.0
VminFLAPS 100.0
VmaxFLAPS 230.0
Vz_climb 8.4
V_climb 256.0
T_turn 15.0
V_turn 310.0
K_max 11.23
Cy0_max 0.21
FlapsMult 1.0
FlapsAngSh 4.0
Range 652.0
CruiseSpeed 282.0
SensYaw 0.42
SensPitch 0.60
SensRoll 0.32
[Polares]
lineCyCoeff 0.082
AOAMinCx_Shift 0.4555
Cy0_0 0.21
AOACritH_0 19.50
AOACritL_0 -18.0
CyCritH_0 1.35 // Cy 1.6x0.94-10%=Cy_max 1.35
CyCritL_0 -0.90
CxMin_0 0.032
parabCxCoeff_0 4.2E-4
Cy0_1 0.70 // Cy 55.74+32%=73.6+5(Cy0 + 0.05)=78.6x0.90(Cy1.35:1.50)=0.70
AOACritH_1 16.50
AOACritL_1 -20.0
CyCritH_1 1.80 // Cy 1.52+32%=2.0x0.90(Cy1.35:1.50)=1.80
CyCritL_1 -0.72
CxMin_1 0.102
parabCxCoeff_1 4.2E-4
parabAngle 4.5
Decline 0.006
maxDistAng 38.0
draw_graphs 0
[SOUND]
Engine Std
Код:
[R-1535-SB4-G/Twin-Wasp/SBC-3]
Type Radial
Autonomous 1
Cylinders 14
Extinguishers 4
Carburetor 1
Direction Right
HorsePowers 715.0
BoostFactor 1.0
WEPBoostFactor 1.154
cAfterburner 1
AfterburnerType 11
cMix 1
MixerType 2
MixerAltitude 2000
PropMass 140.0
RPMMin 200
RPMNom 2550
RPMMax 2550
RPMMaxAllowed 3060
Reductor 0.75
PropDiameter 3.0
PropAnglerType 2
PropAnglerSpeed 0.092
PropAnglerMinParam 1912.5
PropAnglerMaxParam 2550.0
PropAnglerAfterburnerParam 2625.0
PropPhiMin 15.0
PropPhiMax 40.0
PropAoA0 11.0
Voptimal 280.0
cCompressor 0
CompressorType 1
CompressorSteps 1
CompressorRPMCurvature 4.2
CompressorPMax 1.54
CompressorAltitude0 2743.0
CompressorMultiplier0 1.050
CompressorBaseMultiplier0 1.050
CompressorRPMP0 1600.0
CompressorRPMPMax 2625.0
CompressorMaxATARPM 1.37
CompressorSpeedManifold 0.65
CompressorRPM0 450
CompressorATA0 0.40
CompressorRPM1 1000
CompressorATA1 0.60
CompressorRPM2 1200
CompressorATA2 0.65
CompressorRPM3 1800
CompressorATA3 0.95
CompressorRPM4 2000
CompressorATA4 1.00
CompressorRPM5 2400
CompressorATA5 1.30
CompressorRPM6 2550
CompressorATA6 1.37
// CompressorRPM7 2625
// CompressorATA7 1.54
DisP0x 2550
DisP0y 0
DisP1x 0
DisP1y 50
cRadiator 1
TESPEED 0.021
TWATERMAXRPM 192
TOILINMAXRPM 70
TOILOUTMAXRPM 95
MAXRPMTIME 600
MINRPMTIME 999
TWATERMAX 232
TWATERMIN 130
TOILMAX 120
TOILMIN 40
---------------
Хелдивер немного настроен
- фм ниже в архиве.
Замечания принимаются!
Приятных полётов!
-------------
П.С.
Проверял в патче 4.12.2.
Колодки ставятся, воздушный тормоз работает - есть снижение скорости,
автопилот работает корректно.
Скорости на высоте 3500 и 4700 метров боле-мение исторические.
Плохо набирает высоту.
